SF-EH3 Automatic Three-servo Box Motion Packaging Machine
SF-EH3 Automatic Three-servo Box Motion Packaging Machine
Area of application:
Suitable for compact packaging of tall items, shorter bags and long items. Quick-frozen products, large tray products, etc.
| Model |
SF-EH3 590/120 |
SF-EH3 590/150 |
SF-EH3 680/120 |
SF-EH3 680/150 |
SF-EH3 720/150 |
|
Packaging material max. width (mm) |
<560 | <560 | <650 | <650 | <680 |
|
Product size L: length (mm) B: width (mm) H: height (mm) |
L: 100-300 B: 30-170 H: 15-80 |
L: 120-350 B: 30-170 H: 30-100 |
L: 100-300 B: 30-260 H: 15-80 |
L: 120-350 B: 30-260 H: 30-100 |
L: 120-350 B: 60-260 H: 30-100 |
| without gusset: B+H < 200 | without gusset: B+H < 300 | ||||
|
Stable production capacity (bags/min) |
30-80 | 30-70 | 30-70 | 30-70 | 30-50 |
|
Dimensions (mm) |
4730*1200*1800 (includes 3000mm conveyor)
|
4730*1300*1800 (includes 3000mm conveyor) |
|||
| Packaging material | Composite films suitable for heat-sealing packaging: paper/PE, OPP/PE, PT/PE, AL/PE, etc. | ||||
|
Total weight (kg) |
1200 | 1300 | |||
| Motor power | One packaging machine motor 1.5KW; one film motor 0.75KW; one input conveyor motor 0.75KW | ||||
| Electric heating power | 450W*2; 400W*4 | ||||
| Power supply | Single-phase 220V, 50Hz | ||||
| Total Power |
6KW (with no additional function) |
||||
Qingdao Songben Packing Machinery Co., LtdWas established in November 1, 2003, is a professional manufacturer automatic pillow packing machine, large-scale automatic Gong material production lines, packaging machinery related to supporting electronic products, international import and export trade of the national high-tech enterprises.
