SF-CW Automatic Multi-row Packaging Machine without tray

Number of views:
1000

SF-CW Automatic Multi-row Packaging Machine without tray

Suitable for multi-row biscuits, fragile biscuits, family packs of wafers and egg yolk pie, etc.
Retail price
0.0
Market price
0.0
Number of views:
1000
Product serial number
Quantity
-
+
Stock:
0
Product description
Parameters
Area of application:

Suitable for multi-row biscuits, fragile biscuits, family packs of wafers and egg yolk pie, etc.

Special recommendation:

This machine is specially designed for international market of large-scale family packs, and at the same time, filling the technical gap of domestic market. With the continuous growing of family pack market, the invention of this machine will be greatly used in the family packing area.

Machine features:

1. Imported PLC control.

2. Adopting AC motor with frequency converter to realize stepless variable speed control, which can be dynamically adjusted during operation.

3. Adopting photoelectric detection and two-way tracking can effectively eliminate packaging errors and avoid material waste.

4. The new horizontal sealing design allows sealing at a low temperature, reducing packaging material waste and film scalding during power-off.

5. The HMI adopts monitoring of bag length, packaging speed, etc.

6. The product is packed in multiple rows,save the need for trays and packaging costs.

7. Adopting strong and compact structure to allow operation with low noice and high stalibility.

8. Advanced technologies and safety protections such as protection covers, overload protection, electric shock protection, and alarm warning.



Models SCW
450/99
SCW
450/120
SCW
450/150
SCW
590/99
SCW
590/120
SCW
590/150
SCW
590/180
Packaging materials
max. width (mm)
<450 <450 <450 <590 <590 <590 <590
Product Size
L: length (mm)
B: width (mm)
H: height (mm)
L:90-400
B:10-150
H:5-40
L:100-400
B:10-150
H:10-60
L:120-450
B:10-150
H:30-75
L:90-400
B:30-200
H:5-40
L:100-400
B:30-200
H:10-60
L:120-450
B:30-200
H:30-75
L:140-480
B:30-200
H:40-100
Production capacity
(bags/min)
15-80 15-80 15-60 15-80 15-80 15-60 15-60
Dimensions (mm) 5000×900×1750 5000×1040×1750
Packaging materials Composite films suitable for heat-sealing packaging: paper/PE, OPP/PE, PT/PE, AL/PE, etc.
Total weight (kg) 1000 1000 1000 1200 1200 1200 1200
Motor power One packaging machine motor 1.1KW; one or two 60W control motor.
Electric heating power 450W*2
400W*4
Power supply Single-phase 220V,50HZ
Total power 3.66KW 3.66KW 3.66KW 3.66KW 3.66KW 3.66KW 3.66KW



According to different packaging materials and packaging requirements, the specific technical parameters will change, and the final parameters confirmed by both parties shall prevail.
